Permanent magnet synchronous motor 100KW

Product name: Permanent magnet synchronous motor 100KW.

Model:TZ368X1000S01

Special features of permanent magnet synchronous motor

Permanent magnet synchronous motor has small volume, light weight, low loss, high efficiency, wide range of constant power, wide speed range and high efficiency range etc, favored by the oems, the market share of 90% or more.


Product Introduction

In order to better meet the demand of the permanent magnet synchronous motor, the electric motor of the company can meet the following requirements:

 Optimization design of electromagnetism simulation and test performance of electromotor;

 Structure strength simulation and optimization design of test;

 Optimization design of thermal management system;

 Optimal design of fluid simulation;

 Meet the design requirements of motor performance, structure and process of motor vehicle.

 Aiming at the requirements of vehicle operating conditions and road conditions, the design of the specific motor product requirements;

 The test of motor overall performance is carried out by the NEDC motor, which can be used to calculate the range of the whole vehicle without the installation.

Name

100kw Drive motor

The performance parameters

Continuous power/peak power

100/150kw

Continuous torque/peak torque

400/850Nm

Rated speed/maximum speed

2400/4500Nm

Maximum motor

           efficiency

96%

Battery voltage (DC)

540V

The motor size

Φ410*300mm

Protection grade

IP67

Insulation class

Class H

Motor weight

100kg

Suitable for bus, minibus, truck, etc
